Vega DL32-100-2 Vertical Multistage Pump 18.5 kW, 175 m Head

Description

Overview

The DL32-100-2 is a vertical multistage centrifugal pump that delivers up to 40 m³/h at a maximum head of 175 m, sized for a 18.5 kW motor. It is built for high-head duties, with a stainless steel impeller stack that builds pressure in stages for tall buildings, process plants and long irrigation lines. Many close neighbours in the DL range share a motor size but differ in head, so check the 175 m figure against your duty before you order.

This listing is for the pump wet end only. The motor is sold separately, so you pick the voltage and make that fits your supply. Ask us for a complete pump and motor package and we will size it to your voltage and application.

Key features

• Stainless steel impeller stack in a vertical multistage design with a compact footprint.
• Maximum flow 40 m³/h and maximum head 175 m on the DL32-100-2 multistage pump.
• Rated motor power 18.5 kW, supplied as a wet end so you can match the motor to your site.
• Motor options: 3 phase 380 V 50 Hz as standard, with 220 V and 525 V motors also available.
• Delivered as a pump end only, which keeps the price down if you already have a suitable motor.

Where it works

The DL32-100-2 multistage pump is built for demanding duties such as high-rise building water supply, industrial process water, large-scale agricultural irrigation, mine dewatering support and fire-protection backup systems. Typical sites are Gauteng towers and plant rooms, Mpumalanga coal-belt mines, and Western Cape vineyard irrigation schemes where the lift or line pressure is high.

What’s in the box

• DL32-100-2 vertical multistage pump wet end
• No motor included, motor sold separately

Delivery and warranty

Kamano delivers with its own trucks from Polokwane to all nine provinces in 1 to 3 days, including Tzaneen, Welkom, Pretoria, Gqeberha, Mbombela and East London. The shipping weight is 125 kg, which puts delivery in the over 100 kg category, delivered on quotation. Orders of R20,000 or more (VAT incl.) ship free. Browse more multistage pumps, or compare the DL32-10 2.2kW vertical multistage pump and the DL32-100 18.5kW vertical multistage pump. Ask us for the warranty terms on this model.
