Vega DL12-140 11 kW Vertical Multistage Pump, 168 m Head

Description

Overview

The Vega DL12-140 is an 11 kW class vertical multistage pump end that gives up to 16 m³/h at a maximum head of 168 m. It is aimed at applications that need high head at a steady flow rate, where you want efficient, long-lasting performance from a proven design. The listing covers the pump wet end only, so the 11 kW motor is chosen and bought separately. Compare it with the DL12-120 at 7.5 kW or the DL12-160 at 192.5 m, or browse all multistage pumps.

Key features

• Maximum head of 168 m
• Maximum flow of 16 m³/h
• Stacked stainless steel impeller stack, vertical multistage centrifugal design
• 11 kW rated motor power, 380 V three-phase 50 Hz standard, with 220 V and 525 V motor options
• Wet end only, so the motor can match your supply

Where it works

At 11 kW this pump is for commercial and industrial duty rather than a household tank. It handles pressure boosting in multi-storey buildings in Johannesburg and Pretoria, reverse osmosis feed water for treatment plants, medium-scale irrigation on Free State grain farms, and general industrial water transfer on mines and depots. It is a sensible choice when a lower-power pump cannot hold pressure at the far end of a long reticulation line. Give us your flow, head and pipe size and we will verify the fit.

What’s in the box

• Vega DL12-140 vertical multistage pump end
• Motor not included, sold separately

Delivery and warranty

Kamano delivers with its own trucks from Polokwane to all nine provinces in 1 to 3 days, including Johannesburg, Pretoria, Welkom, Klerksdorp, Mbombela and Durban. Shipping weight is about 40 kg, which falls in the 30 to 60 kg band at R950. Fees are set by total order weight: up to 30 kg R550, 60 to 100 kg R1,450, over 100 kg on quotation. Orders of R20,000 or more (VAT incl.) are delivered free. Ask us for the warranty terms on this model.
