DL Pump Motor 3 kW, 380 V Three-Phase, Frame 100L

Name: DL Pump Motor 3 kW, 380 V Three-Phase, Frame 100L
SKU: KMN-PUMP-0036

SKU KMN-PUMP-0036

A 3 kW, 380 V three-phase motor in frame 100L for DL vertical multistage pumps, supplied to order and delivered across South Africa.

Request a Quote

Drives DL pumps in the DL5, DL8, DL12, DL16, DL32 and DL45 families
3 kW (4 HP), 2-pole, about 2900 rpm
380 V three-phase, 50 Hz supply
Frame 100L, B14 small face flange
Price on request, special order item

Request a Quote Ask on WhatsApp

Delivered by our own trucks in 1 to 3 days. R550 / R950 / R1,450 by order weight. FREE on orders of R20,000 or more with code KH027. Delivery details

Specifications

Motor power	3 kW (4 HP)
Voltage / phase	380 V three-phase, 50 Hz
Speed	2-pole, about 2900 rpm
Frame size	100L
Mounting	B14 small face flange (F100L B14S)
Compatible pumps	DL5: DL5-180, DL5-200; DL8: DL8-70, DL8-80, DL8-90; DL12: DL12-40, DL12-50; DL16: DL16-30; DL32: DL32-20-2; DL45: DL45-10-1
Starter / protection	Needs a motor starter with overload protection, or a VSD
Supply required	Three-phase
Price	On request (special order item)
Net weight	22 kg
Shipping weight	24 kg
Dimensions	380 x 200 x 250 mm

Description

Overview

This 3 kW (4 HP), 380 V three-phase motor in frame 100L is the drive end for DL vertical multistage pumps in the DL5, DL8, DL12, DL16, DL32 and DL45 families. The DL pump ends are sold without a motor, so you need one to complete a new pump or to replace a burnt-out motor.

It is a compact 100L frame with a B14 small face flange (F100L B14S), so it face-mounts to the pump head. The 2-pole winding turns at about 2900 rpm on a 50 Hz supply.

380 V three-phase is the common supply on farms and industrial sites. It needs a three-phase supply, so a house or small farm on 220 V single-phase will need a different motor.

Match the motor to your pump model using the Compatible pumps row in the specs, and to the supply you have on site. If you are unsure, send us the pump model and a photo of your DB board and we will confirm the right motor. The full multistage pump range has the pump ends, seals and stacks too.

Key features

3 kW (4 HP) rated output, 2-pole, about 2900 rpm
Runs on a 380 V, 50 Hz three-phase supply
Frame 100L with B14 small face flange (F100L B14S)
Fits DL5, DL8, DL12, DL16, DL32 and DL45 pump families, full model list in the specs
Needs a motor starter with overload protection, or a VSD
Special order item, quoted with lead time on request

Where it works

Farms in Limpopo, the Free State and KwaZulu-Natal, and industrial yards on 380 V three-phase, use this motor to drive DL pumps for irrigation boosting, wash-down lines and plant water supply. At this size it usually drives pressure boosting for a large home, a lodge or a small farm water scheme. Related motors: 3 kW 525 V DL pump motor, frame 100L and 4 kW 380 V DL pump motor, frame 112M.

What’s in the box

1 x 3 kW 380 V three-phase motor, frame 100L
Pump end, motor starter and cabling are not included

Delivery and warranty

Kamano delivers with its own trucks from Polokwane to all nine provinces in 1 to 3 days, with regular runs to Tzaneen, Richards Bay, Klerksdorp, Pretoria, Durban and Bloemfontein. Shipping weight is about 24 kg. That falls in the up to 30 kg delivery band (R550). Free delivery applies to orders of R20,000 or more (VAT incl.). The price is on request because this is a special order item. Ask us for the warranty terms on this model.

Questions about this product

Which DL pumps does the 3 kW 380 V motor fit?

It suits DL pumps in the DL5, DL8, DL12, DL16, DL32 and DL45 families. The full model list is in the Compatible pumps row of the spec table. Check the model on your pump nameplate against that list before ordering, and send us a photo of the nameplate if you are unsure, so we can confirm the motor fits your pump head.

Can I run this motor on 220 V single-phase?

No. This is a 380 V three-phase motor at 50 Hz, so it needs a three-phase supply and a motor starter with overload protection, or a VSD. Houses and small farms normally run 220 V single-phase, and those sites need a different motor. Send us your pump model and a photo of your DB board and we will confirm the right one.

Do you deliver a 3 kW motor to Tzaneen?

Yes, we deliver to Tzaneen and all nine provinces with our own trucks from Polokwane in 1 to 3 days. This motor ships at about 24 kg. That falls in the up to 30 kg delivery band (R550). Delivery is charged by total order weight and is free on orders of R20,000 or more (VAT incl.).

How much does this motor cost and what is the lead time?

It is a special order item, so the price is on request. Contact us with your pump model and supply voltage and we will quote the price and lead time. Delivery fees are charged by total order weight and are free on orders of R20,000 or more (VAT incl.).
