5000 L Tank and 1.5 kW VSP Booster Pump System with VSD
SKU KMN-WATR-0332
A 5000 L tank with a 1.5 kW VSP variable-speed booster pump system on 220 V, plus filter and UV steriliser, delivered across South Africa.
R16 312,59
- 5000 L tank with VSP 1.5 kW variable-speed booster pump system with VSD, 220 V, filter and UV steriliser in one kit
- Variable speed drive adjusts the motor to demand, so pressure stays steady when taps open and close
- Includes pump house cover, pipe set with ball valves and float valve
- Ships at 124 kg, delivered nationwide from Polokwane
Delivered by our own trucks in 1 to 3 days. R550 / R950 / R1,450 by order weight. FREE on orders of R20,000 or more with code KH027. Delivery details
Specifications
| Tank capacity | 5000 L nominal, 5325 L maximum |
|---|---|
| Tank material | Rotomoulded virgin LLDPE with black inner liner |
| Tank diameter × height | 1800 mm × 2200 mm, 450 mm manhole |
| Pump type | VSP booster pump system with variable speed drive, 1.5 kW |
| Flow rate | Up to 108 L/min |
| Max head / pressure | Up to 60 m head |
| Voltage / phase | 220 V single phase |
| Inlet / outlet | On request |
| Self-priming | On request |
| Duty cycle | On request |
| Fluid compatibility | Clean water up to 40 °C |
| UV steriliser | 55 W, 304 stainless steel casing, 2700 L/h, 1 in inlet and outlet |
| Filter | 3-stage wall mount, 20 inch cartridges (5 micron PP, GAC, nano silver CTO), 5 bar, 50 °C max |
| Float valve | Brass, 15 mm, 6 bar max |
| Pump house | Grey plastic cover included |
| Warranty | Tank: 1 to 2 years, depending on the model |
| Net weight | 120 kg |
| Shipping weight | 124 kg |
| Dimensions | 1800 × 1800 × 2200 mm |
Description
Overview
This 5000 L kit is built around a 1.5 kW VSP booster pump system with a variable speed drive. The drive changes the motor speed to match demand, so pressure holds steady whether one tap or six are open.
Output reaches 108 L/min at up to a 60 m head, and it runs on a normal 220 V single-phase supply. That makes it the pick for a large homestead, a lodge or a staff compound where a fixed-speed pump would surge and bang the pipes.
Shopping for a water tank with vsd booster pump? Browse more in our tank and pump combo kits, or compare it with the 5000 L combo with a 0.75 kW Intelli VSD booster pump or the 5000 L combo with a 1.5 kW Intelli VSD booster pump.
Key features
- Variable speed drive adjusts the motor to demand, so pressure stays steady when taps open and close
- Up to 108 L/min at a 60 m head from a 220 V single-phase supply
- Fluid and ambient temperature up to 40 °C
- UV steriliser and 3-stage filter included
- Heaviest pump kit in the 5000 L range, built for the biggest homesteads
- Black inner liner on the tank helps keep algae down
- Pump house cover, ball-valve pipe set and float valve supplied
Where it works
It fits game lodges in Limpopo, large Gauteng smallholdings, wine estates in the Western Cape and school hostels in KZN. Anywhere pressure needs to stay constant across showers, kitchens and garden taps, a variable-speed system earns its price.
What’s in the box
- 5000 L vertical LLDPE water tank
- VSP 1.5 kW variable-speed booster pump system with VSD, 220 V
- 3-stage wall-mount filter (5 micron PP, GAC and nano silver CTO cartridges) with spanner
- 55 W UV steriliser, 304 stainless steel casing
- Grey plastic pump house cover
- Tank-to-pump pipe set with ball valves
- 15 mm brass float valve kit with ball
Delivery and warranty
Kamano delivers with its own trucks from Polokwane to all nine provinces in 1 to 3 days, and delivery is free on orders of R20,000 or more (VAT incl.). This combo ships at 124 kg, so delivery is quoted for your site. The tank carries a warranty of 1 to 2 years, depending on the model, confirmed on your quote. Ask us for the pump warranty terms.
Questions about this product
What does the VSD on this pump actually do?
The variable speed drive slows the motor when demand is low and speeds it up when more taps open. You get steady pressure, fewer start-stop cycles and less water hammer in the pipes. A fixed-speed pump switches fully on and off instead, which is harder on the motor and the fittings.
Is the tank really 5000 litres and how big is it?
The tank is a 5000 L nominal vertical rotomoulded LLDPE tank that holds up to 5325 L when filled to the brim. It stands about 2200 mm high on a 1800 mm diameter footprint, with a 450 mm manhole. Prepare a level, firm base before delivery, because a full tank weighs over five tonnes.
Do I need three-phase power for the 1.5 kW pump?
No. This system is specified for 220 V single phase, so it runs off a standard farm or house supply. Have an electrician fit a correctly rated breaker and earth leakage protection. If you want it to run during load-shedding, ask us about inverter sizing for the start-up load.
How much is delivery on this tank combo, and do you deliver to my farm?
We deliver with our own trucks from Polokwane to all nine provinces in 1 to 3 days. This combo ships at 124 kg, which is over 100 kg, so the delivery fee is on quotation. Send us your town or farm address and we will quote you. Orders from R20,000 VAT incl. get free delivery.
Nationwide delivery from Polokwane
Delivered to all nine provinces in 1 to 3 days
We deliver the 5000 L Tank and 1.5 kW VSP Booster Pump System with VSD with our own trucks to Johannesburg, Pretoria, Cape Town, Durban, Gqeberha, Bloemfontein, Polokwane, Mbombela, East London, Klerksdorp, Stellenbosch, Mahikeng, Thohoyandou and Kimberley, and to farms, mines and sites in between. This item ships in the delivery on quotation (over 100 kg). Orders of R20,000 or more deliver free with code KH027.
