Plast Compression Reducing Tee for HDPE Pipe, 25 mm to 50 mm

Description

Overview

The compression reducing tee branches a smaller HDPE pipe off a larger main line using one fitting. It has three compression connections, with the branch outlet sized down so you can run a 25 mm feed off a 40 mm main, for example, without a separate reducer. No heat or soldering is involved.

Inside, a rubber O-ring seals each pipe, so the joints stay watertight on straight pipe or a slight bend. The body is polypropylene, the rating is PN16 (16 bar) and the manufacturer states it is made to ISO 14236 and SANS 14236.

Key features

• Three-way compression tee for HDPE pipe
• Reduced branch for a smaller pipe size
• Strong polypropylene construction
• Rubber O-ring seal on every connection
• PN16 rating, 16 bar
• Suits high-pressure and low-pressure water lines
• Fine for outdoor and underground water systems
• No heat, glue or soldering needed

Options

The first size is the main line and the second is the branch. Prices include VAT.

• 25 x 20 mm: R 41
• 32 x 20 mm: R 69
• 32 x 25 mm: R 69
• 40 x 25 mm: R 62
• 40 x 32 mm: R 94
• 50 x 25 mm: R 97
• 50 x 32 mm: R 102
• 50 x 40 mm: R 150

Where it works

Reach for it on farm water supply, irrigation networks, tank installations and general HDPE pipework, such as a Western Cape vineyard block fed off a larger main, or a Free State stock-water line with a branch to a trough. Cut the pipe square, remove rough edges, push each pipe in fully, then tighten the blue nuts evenly and check all three joints before pressurising. If both ends of your joint run in a line, a reducing coupler is neater. For a threaded take-off, look at the male tee. All are listed under pipe fittings.

What’s in the box

• 1 x compression reducing tee in the size pair you select

Delivery and warranty

Kamano delivers with its own trucks from Polokwane to all nine provinces in 1 to 3 days, including Cape Town, George, Upington, Johannesburg, Welkom and Bloemfontein. The heaviest option ships at about 0.4 kg, inside the R550 band for orders up to 30 kg. Delivery is free on orders of R20,000 or more (VAT incl.). Ask us for the warranty terms on this model.
