4SD4/10 solar borehole pump kit, 1.1 kW, 78 m head, hybrid AC/DC inverter

4SD4/10 Solar Borehole Pump Kit, 1.1 kW Hybrid AC/DC, 78 m Head

Name: 4SD4/10 Solar Borehole Pump Kit, 1.1 kW Hybrid AC/DC, 78 m Head
SKU: KMN-SOLR-0031
Price: 11288.00 ZAR
Availability: InStock

SKU KMN-SOLR-0031

A 1.1 kW hybrid solar borehole pump kit for 4 inch boreholes, lifting water up to 78 m at 6.2 m³/h, delivered across South Africa from Polokwane.

R11 288,00

Solar by day, automatic mains or generator backup when the sun is short
Lifts water up to 78 m at up to 6.2 m³/h
1.1 kW brushless DC motor, stainless steel 4 inch wet end
Hybrid AC/DC inverter included, built for a 2,200 W array

Delivered by our own trucks in 1 to 3 days. R550 / R950 / R1,450 by order weight. FREE on orders of R20,000 or more with code KH027. Delivery details

Specifications

Flow rate	Up to 6.2 m³/h
Max head / pressure	78 m
Voltage / phase	PV input 450V/150V, with hybrid AC mains or generator input
Power	1.1 kW brushless DC motor
Inlet / outlet	On request
Self-priming	N/A (submersible)
Duty cycle	Daylight operation on solar, automatic mains or generator backup
Fluid compatibility	Non-corrosive water, sand up to 1% by volume, liquid up to 40 °C
Pump wet end	Stainless steel, 4 inch
Controller	Hybrid AC/DC inverter
Recommended solar array	2,200 W (4 x 550 W panels)
Recommended water level	Up to about 59 m
Minimum borehole size	4 inch (100 mm)
Net weight	21 kg
Shipping weight	25 kg
Dimensions	1100 × 250 × 250 mm

Description

Overview

The 4SD4/10 is a 1.1 kW solar borehole pump kit that lifts water up to 78 m at up to 6.2 m³/h, and keeps running on mains or generator power when the sun drops out. It pairs a stainless steel 4 inch submersible wet end with a brushless DC motor and a hybrid AC/DC inverter, so one controller handles both solar and backup supply.

The kit is built around a 2,200 W array: 4 standard 550 W panels wired together at 450V/150V. That is deliberately above the motor rating to cover cloud and losses. A different panel wattage changes the count, and our team can confirm the layout.

It is rated for a dynamic water level of about 59 m. For a deeper borehole or a different flow rate, ask us about the other 4SD configurations, which run up to 240 m head. See also the solar borehole pumps range, including the 4SD4/10 solar borehole pump kit, 61 m head and the 4SD4/18 solar borehole pump kit, 128 m head.

Key features

Hybrid solar system: runs on solar power during the day and draws AC mains or generator power automatically when the sun is not enough
Stainless steel 4 inch submersible wet end with a brushless DC motor and 100% copper windings
Hybrid AC/DC inverter is included, so no separate changeover gear is needed
Soft-start control with protection against under-voltage, over-voltage, overload and dry running, with automatic recovery after waterless faults
Maintenance-free and straightforward to install
Fits 4 inch (100 mm) and larger boreholes, wells and reservoirs

Where it works

Free State and North West grain and livestock farms use kits like this to fill a header tank while keeping a mains or generator fallback for weeks of heavy cloud. It also suits guesthouses, school and church boreholes, and small commercial sites in Mpumalanga and KwaZulu-Natal that need water every day of the week.

What’s in the box

4 inch stainless steel submersible pump end
Brushless DC motor, 1.1 kW
Hybrid AC/DC inverter
Solar panels, cable and rising main are not part of the kit; ask us to quote them

Delivery and warranty

Kamano delivers with its own trucks from Polokwane to all nine provinces in 1 to 3 days, with regular runs to East London, Upington, Mahikeng, Johannesburg, Durban and Polokwane. The boxed kit ships at about 25 kg, which falls in the up to 30 kg delivery band (R550). Orders of R20,000 or more (VAT incl.) are delivered free. Ask us for the warranty terms on this model.

Questions about this product

How many solar panels do I need to run the 4SD4/10 at 78 m head?

The kit is designed for 4 standard 550 W panels, a 2,200 W array wired together at 450V/150V. That is intentionally above the 1.1 kW motor rating to cover cloud, cable and controller losses. If you use panels of a different wattage the count changes, so tell us what you have and we will confirm the layout for your site.

What happens on a cloudy day or at night?

Because the inverter is hybrid, it draws AC power from the mains or a generator automatically when solar output drops, so water keeps flowing. Without a backup supply the pump slows and stops with the sun, so we still recommend a storage tank sized for a day or two of use on any solar borehole system.

Is this pump right for my borehole?

It fits 4 inch (100 mm) and larger boreholes. The kit is rated for a dynamic water level of about 59 m, with a maximum head of 78 m and up to 6.2 m³/h. If your water level is deeper or you need more flow, ask us about the other 4SD kits in the range, which run up to 240 m head.

Do you deliver the 4SD4/10 kit to Tzaneen?

Yes. We deliver with our own trucks from Polokwane to all nine provinces in 1 to 3 days, including Tzaneen. This kit ships at about 25 kg, so it falls in the up to 30 kg delivery band (R550). Orders of R20,000 or more (VAT incl.) are delivered free.

Can it pump sandy or dirty water?

It is meant for non-corrosive water with sand content of no more than 1% by volume and a liquid temperature up to 40 °C. A heavily sandy borehole should be developed first, because abrasive water shortens the life of any submersible pump.
