4 Inch DC Brushless Solar Borehole Motor, 0.75 kW 110 V, for TGP Inverter

Description

Overview

This is a 4 inch brushless DC (BLDC) submersible motor rated 0.75 kW at 110 V DC, built to be driven by the TGP hybrid solar inverter. It fits the standard 4 inch 4SD pump ends and goes into boreholes of 100 mm and larger, so you can turn a borehole pump into a solar pump, and Kamano delivers it nationwide.

The motor does not come with a controller. You pair it with the TGP hybrid inverter, which is sold separately, and the inverter takes care of solar input and AC backup.

On panels, the manufacturer specifies 3 x 550 W solar panels for this motor, about 1,650 W in total. Smaller panels mean you need more of them, and your installer can confirm the wiring for your site.

Key features

• 4 inch brushless DC (BLDC) submersible design
• 0.75 kW at 110 V DC
• Fits standard 4 inch 4SD pump ends
• Driven by the TGP hybrid solar inverter
• Fits boreholes of 100 mm and larger
• Sized for 3 x 550 W panels

Where it works

Use it when you already own a 4SD pump end and want to run it on solar, or when you are building a hybrid system from parts for a Limpopo or Mpumalanga farm.

If you would rather buy everything in one box, look at the complete solar borehole pump kits, such as the 4SD6/15 hybrid solar kit at 98 m head, or the 4SD6/20 hybrid solar kit at 118 m head.

What’s in the box

• 4 inch brushless DC submersible motor

Delivery and warranty

Kamano delivers with its own trucks from Polokwane to all nine provinces in 1 to 3 days, including Mbombela, Tzaneen, Polokwane, Richards Bay, Pretoria and Durban. This item ships at about 8 kg, so it sits in the lightest delivery band. Delivery fees are by total order weight: up to 30 kg R550, 30 to 60 kg R950, 60 to 100 kg R1,450, and over 100 kg on quotation. Orders of R20,000 or more (VAT incl.) are delivered free. Pump end, panels and inverter are sold separately. Ask us for the warranty terms on this model.
