DL20-30 vertical multistage pump wet end, 4kW, 28 m³/h, 40 m head

DL20-30 Vertical Multistage Pump Wet End, 4kW, 40 m Head

Name: DL20-30 Vertical Multistage Pump Wet End, 4kW, 40 m Head
SKU: KMN-PUMP-0218
Price: 13014.00 ZAR
Availability: InStock

SKU KMN-PUMP-0218

A 4 kW class vertical multistage pump wet end for boosting and water supply, up to 28 m³/h and 40 m head, delivered across South Africa from Polokwane.

R13 014,00

Up to 28 m³/h and 40 m head
3-stage vertical design, stainless steel impeller stack
4 kW, 3 phase 380 V rated, motor sold separately
R 13,014 VAT incl., delivered from Polokwane

Delivered by our own trucks in 1 to 3 days. R550 / R950 / R1,450 by order weight. FREE on orders of R20,000 or more with code KH027. Delivery details

Specifications

Model	DL20-30
Type	Vertical multistage centrifugal pump, wet end only
Stages	3
Maximum flow rate	28 m³/h (467 L/min)
Maximum head	40 m
Rated motor power	4 kW (motor sold separately)
Voltage / phase	3 phase, 380 V, 50 Hz (220 V and 525 V motor options available)
Inlet / outlet	On request
Self-priming	No
Fluid compatibility	Clean water
Construction	Stainless steel impeller stack
Motor included	No
Net weight	22 kg
Shipping weight	26 kg
Dimensions	280 x 220 x 478 mm

Description

Overview

The DL20-30 4 kW vertical multistage pump delivers up to 28 m³/h (467 L/min) and up to 40 m of head from a 3-stage stainless steel impeller stack.

This Kamano listing is for the pump wet end only. The motor is sold separately, so you choose the voltage and enclosure that suit your site. The range is built around a 4 kW three-phase 380 V, 50 Hz motor, with 220 V and 525 V motor options available. Ask us for a complete pump and motor package quote sized to your supply and duty.

At up to 40 m of head this is a low-pressure, high-flow selection. It is the right call when you need volume for tank filling, garden irrigation or domestic boosting rather than a big pressure rise. Maximum flow and maximum head are not available at the same time, so size the pump against your real duty point.

Key features

Flow of up to 28 m³/h and head of up to 40 m
3 stages in a stainless steel impeller stack
Rated motor power of 4 kW, motor not included
Vertical multistage centrifugal design with a compact footprint
Three-phase 380 V, 50 Hz, with 220 V and 525 V motor options

Where it works

Typical jobs in the Free State include borehole water supply, rainwater harvesting, domestic pressure boosting, garden irrigation and small rural water schemes. Pair it with a pressure tank or controller and it keeps taps and sprinklers steady. A DL20-30 multistage pump suits these jobs well. If this size is not quite right, compare the DL16-40 4kW Vertical Multistage Pump or the DL20 Replacement Hydraulic Stack (Pump Cartridge), or browse all our multistage pumps.

What’s in the box

1 x DL20-30 vertical multistage pump wet end with stainless steel impeller stack
Motor not included: sold separately
Pipework, fittings and controller not included

Delivery and warranty

Kamano delivers with its own trucks from Polokwane to all nine provinces in 1 to 3 days, including Bloemfontein, Kimberley, Upington, Richards Bay and Pretoria. This DL20-30 multistage pump ships at about 26 kg boxed, which falls in the R550 delivery band. Delivery is charged by total order weight: up to 30 kg R550, 30 to 60 kg R950, 60 to 100 kg R1,450, and over 100 kg on quotation. Orders of R20,000 or more are delivered free (VAT incl.). Ask us for the warranty terms on this model.

Questions about this product

Does the DL20-30 come with a motor?

No. Kamano lists the DL20-30 as a wet end only, so the 4 kW motor is sold separately. The range is built around 3 phase, 380 V, 50 Hz motors, and 220 V or 525 V options exist. Tell us your supply voltage and we will quote a complete pump and motor package.

What flow and pressure will I get from the DL20-30?

Up to 28 m³/h and up to 40 m of head. Those are separate maximums, so real flow falls as pressure rises along the pump curve. Give us your required flow, pipe length and height lift, and we will confirm whether the DL20-30 suits, or whether another DL20 size is a better fit.

Do you deliver the DL20-30 to Bloemfontein?

Yes. Kamano delivers with its own trucks from Polokwane to all nine provinces, usually in 1 to 3 days, and Bloemfontein is covered. At about 26 kg boxed this pump sits in the R550 delivery band, and orders of R20,000 or more are delivered free (VAT incl.).

What is the DL20-30 used for?

Low-head duty: tank filling, irrigation, domestic boosting and rural water schemes. Give us your flow, pipe length and lift and we will confirm the size.

Nationwide delivery from Polokwane

Delivered to all nine provinces in 1 to 3 days

We deliver the DL20-30 Vertical Multistage Pump Wet End, 4kW, 40 m Head with our own trucks to Johannesburg, Pretoria, Cape Town, Durban, Gqeberha, Bloemfontein, Polokwane, Mbombela, George, Mokopane, East London, Mahikeng, Kimberley and Thohoyandou, and to farms, mines and sites in between. This item ships in the R550 delivery band (up to 30 kg). Orders of R20,000 or more deliver free with code KH027.
